Type |
6-Cylinder ; 4-Strock |
Air Intake Type |
Turbocharged & Intercooling |
Cooling Mode |
Water Cooling |
Governor Mode |
Electronic |
Bore x Stroke (mm) |
123 x 155 |
Compression Ratio |
17.5:1 |
Rated Speed (rpm) |
1500 |
Displacement (L) |
11.05 |
Rated Power (without fan)(kW) |
300 |
Standby Power (without fan)(kW) |
330 |
Oil Consumption (L/h) |
0.06 |
Steady State Speed Regulation (%) |
<3 |
Oil Capacity Including Filter (L) |
38 |
Emission Compliant |
Stage || |
The Flywheel Shell Interface |
SAE1 |
Flywheel for 14″ Flexible Coupling |
Dry Weight of Base (kg) |
1050 |
Dry Weight of Gen Pac (kg) |
1435 |
Overall Dimension (base)(mm) |
1365 x 773 x 1192 |
Overall Dimension (G.P)(mm) |
2300 x 1120 x 1580 |
Fan Consumption (kW) |
11 |
27C Air Consumption (m3/min) |
21 |
Heat Rejection of Exhaust (kW) |
215 |
Exhaust Gas Temperature After Turbine (C) |
470 |
Exhaust Gas Flow (m3/min) |
60 |
Heat Rejection From Engine (kW) |
18 |
Heat Rejection of Coolant (kW) |
135 |
Base Configuration |
Standard Configuration (add on the base) |
Engine With Fan |
Intake and Exhaust system: Air Filter and Connecting pipes, Connecting Flang of Exhaust Pipe |
Alternator 75A 28V |
Cooling System: Radiator, Connecting Pipes, Fan Guard, Belt Guard |
Starter Motor 7.5kW 24V |
Extendable Base Frame, Manual Oil Drain Pump |
