| Type |
Brush |
| Voltage Regulate |
AVR |
| Frequency Hz |
50 |
| Rated AC Voltage (V) |
230V |
| Rated AC Output (KVA) |
7.5kW / 9.375kVA |
| Peak AC Output (KVA) |
8.0kW / 10kVA |
| Power Factor COS |
1 |
| Rated Current |
±40.9A |
| Model |
TG460 |
| Type |
OHV, 4-stroke, single cylinder, air-cooled |
| Bore x Stroke (mm) |
92 x 69 |
| Displacement (ml) |
458 |
| Max. Output (HP/rpm) |
18 / 3600 |
| Fuel Type |
Unleaded Gasoline |
| Fuel Tank Capacity (L) |
25L |
| Continuous Operating 1/2 load (h) |
13 |
| Engine Oil Standard |
SF or Higher Grade |
| Oil Capacity (L/gal) |
1.1 |
| Ignition System |
T.C.I |
| Starting System |
Recoil Start or Key Start |
| Operating Noise Level (7m) dB (A) |
69 |
| Dimensions (LxWxH)(mm) |
690 x 520 x 570 |
| Net / Gross Weight (kg) |
90 / 92 |
