| Centrifugal Pump Performance Test As Per I.S. 6595 (part 1) : 2002 |
| Model |
TDCS4 |
|
|
|
|
|
|
|
|
Impeller Dia |
| Suction |
100 |
mm |
|
|
|
|
|
|
|
SR. No |
| Delivery |
100 |
mm |
|
|
|
|
|
|
|
Date |
| Speed |
1500 |
rpm |
|
|
|
|
|
|
|
Capacity Measured by 90 “V” Notch |
| Speed |
G. Suc |
G. Del |
G. Dist |
V. Head |
T. Head |
“V” Notch |
Dis. |
M. IP |
P. IP |
P. OP |
C. Dis |
C. Head |
CP. |
EFF. |
| In RPM |
In Meters |
|
In LPS |
In kW |
LPS |
Meters |
kW |
% |
| 1490 |
4 |
3 |
1 |
0 |
8 |
232 |
36 |
6 |
4 |
3 |
36 |
8 |
5 |
62 |
| 1500 |
6 |
3 |
1 |
0 |
10 |
225 |
33 |
6 |
4 |
3 |
33 |
10 |
4 |
72 |
| 1497 |
6 |
4 |
1 |
0 |
11 |
215 |
30 |
5 |
4 |
3 |
30 |
11 |
4 |
72 |
| 1505 |
6 |
6 |
1 |
0 |
12 |
180 |
19 |
5 |
4 |
2 |
19 |
12 |
4 |
56 |
| 1512 |
1 |
11 |
1 |
0 |
12 |
0 |
0 |
4 |
3 |
0 |
0 |
12 |
3 |
0 |
| 0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
– |
– |
– |
– |
– |
| 0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
– |
– |
– |
– |
– |
| 0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
– |
– |
– |
– |
– |
| 0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
0 |
– |
– |
– |
– |
– |
| This Pump is Not Certified As Per I.S. 6595 (part 1 : 2002) |
| Duty Point |
Discharge (i.p.s) |
Head (m) |
Efficiency (%) |
C.P. (kW) |
Head Range (m) |
| Diclartion |
28 |
10 |
72 |
4.8 |
8.0-12.0 |
| Observation |
29.6 |
10.6 |
72 |
4.58 |
OK |
