| Make |
Honda |
| Model |
GX390 |
| Power |
11HP – 8.2kW / 3600Rpm |
| Type |
4-Stroke Air-Cooled Single-Cylinder |
| Displacement |
389cc / 0.389L |
| Fuel Type |
Gasoline |
| Starter |
Recoil Start / Electric Start |
| Consumption |
330 g/kwh – 3.5l/h |
| Noise |
90dB at 7m |
| Fuel Tank Size |
6.1L |
| Oil Tank Size |
1.1L |
| Pump |
|
| Make |
Energie |
| Model |
TPS100 |
| Inlet and Outlet |
4″ 100mm / 4″ 100mm |
| Delivery Volume |
1700 l/min |
| Max Head |
30m |
| Suction Lift |
8m |
| Driving Power |
10.4kW |
| Pump Body |
Aluminium Alloy |
| Impeller |
Cast Iron |
| Mechanical Seal |
Carbon Ceramic |
| Working Speed |
3600Rpm |
| Accessories Included |
Pipe Connector Fittings |
|
2 x 4 inch Pipe Connecting Wrench |
|
Rubber Gaskets |
|
Suction Strainer |
| Inlet Size |
100mm / 4″ |
| Material |
Galvanized Steel |
|
Hose Clamps x3 |
| Recommended Piping |
Inlet Hose |
| Material |
Rubber or Neoprene |
| Type |
Reinforced Synthetic Rubber |
| Thickness |
3-6mm |
|
Outlet Hose |
| Material |
Rubber or Neoprene |
| Type |
Reinforced Synthetic Rubber |
| Thickness |
3-6mm |
| Permissible Pumping |
|
| Allowable Liquids |
Water (fresh, salt, wastewater) |
| Solid Handling |
|
| Pump |
27mm |
| Restricted by Strainer |
19mm |
| Fuels & Lubricants (recommended) |
|
| Gasoline |
95ppm or better |
| Oils |
15W / 40 |
| Consumables (service parts) |
|
| Engine Air Filter |
Contact Dealer Directly |
| Engine Oil Dipstick Assembly |
Contact Dealer Directly |
| Engine Fuel Tank Filter |
Contact Dealer Directly |
| Dimensions & Weights |
|
| Length |
800m |
| Width |
505mm |
| Height |
760mm |
| Dry & Wet Weight |
106.8kg / 114kg |
| Policies |
|
| Warranty |
1 year Limited Warranty |
